Headplay HD FPV Headset with 32ch 5.8Ghz Receiver


#1

We are happy to say that we will soon stock the headplay HD FPV headset in our shop. The headplay HD have been designed by FPV enthusiasts from the ground up with comfort and performance in mind. Unlike other FPV headsets which rest on the bridge of your nose, the headplay HD have a nice head strap that distributes the weight on the forehead and cheeks, making it much more comfortable to wear. The goggles also do an excellent job at blocking out light to the FPV screen.

In contrast to traditional FPV goggles, the headplay HD use a single LCD screen which means that you dont need to care about setting up the interpupillary distance (IPD). With this FPV headset you just look through one beautify large HD display which puts out 1280x800 pixels with a wide 72 degree field of view. The other great thing with these, that if you wear glasses you should be able to use these just fine which is a huge advantage over the fatshark series of FPV goggles.

Integrated 5.8Ghz Receiver

32 channel receiver designed by RangeVideo. Channel compatible with with Boscam/ImmersionRC/Fatshark. Channel switch by pushbutton and LED segment display on top of goggles.

HDMI or External AV Input

Connect the Headplay HD goggles directly to your DJI Inspire or DJI Lightbridge system. See in crystal clear live HD to make better aerial videos. Connect your 900MHz/1.3GHz/2.4GHz external FPV audio video receivers to the Headplay HD with the included harness.

HeadPlay HD Specifications

  • Picture
  • Screen resolution: 1280x800
  • Field of View: 72 degree
  • Fully adjustable picture via intuitive menus
  • General
  • Control via button panel (distinct button design for “blind” operation)
  • Rugged design with extremely durable materials
  • Very high comfort
  • Adjustable straps
  • Different density foam pads allow you to adapt the goggles to your needs.
  • Weight: 400g (excluding battery)
  • Easy to clean optics
  • Electrical Properties
  • Current consumption 340mA@12V
  • Supply voltage: 6-15V Recommended 2S LiPo
  • Reverse voltage protection
  • Connectors
  • HDMI type C (HDMI-in)
  • XS9JK (latched high end connector): Power Supply, Video-in, Audio-in, Ground, 5V out
  • SMA antenna connector
  • Integrated Features
  • 32 channel 5.8GHz A/V receiver
  • 8 segment display
  • Sensitivity: -90dBm
  • Built-in speaker with volume control on buttons
  • Frequencies
  • Band 1: 5725, 5745, 5765, 5785, 5805, 5825, 5845, 5865
  • Band 2: 5733, 5752, 5771, 5790, 5809, 5828, 5847, 5866
  • Band 3: 5705, 5685, 5665, 5645, 5885, 5905, 5925, 5945
  • Band 4: 5740, 5760, 5780, 5800, 5820, 5840, 5860, 5880

Get yours today from Unmanned Tech Shop


HeadPlay HD FPV Headset Quickstart Guide
Will this fpv monitor feed signal
#2

very nice that you will stock them. When will they be available? Any idea yet on price? Cheers


#3

We expect them to only be availabe in about 1 month or so as the manufacturer have a very long lead time. As for price they will be less than £200 inc VAT. I will update this post once we have a confirmed delivery date.


#4

Are there any news on availability yet?


#5

We have been told by the factory that our batch should be shipped in about 2 weeks, so they should be here around the week of 22nd June if all goes smoothly, but I have been told that they are in production right now for us.


#6

Do you know when you will get your next batch of these into the shop?


#7

We should have more in stock in about 1 or 2 weeks as they are already on the way from the factory, but it looks like they will all be white again. Have you signed up for stock notifications on the headplays?


#8

Yeah ive signed up, wasn’t sure if it was colour independent on the stock alert

Thanks for the update
